> GWINSTEK 제품 > AC / DC 전원공급기

전체

ASD-1000 시리즈

  • AC 전원공급기, ASD-1000시리즈
  • 출력 전압 : AC 0~300Vrms
  • 출력 전력 : 6kVA(ASD-1600)/ 9kVA(ASD-1900)
  • 출력 주파수 : 30Hz~1000Hz
  • 인터페이스 : RS-232/GPIB/EXT

AC/DC 전원공급기 ASR-3000 시리즈

  • AC/DC 전원공급기, ASR-3000
  • 출력 전압 : AC 0~400Vrms, DC 0~±570V
  • 출력 전력 : 2kVA/3kVA/4kVA
  • 출력 주파수 : 999.9Hz, 5kHz(ASR-3400HF)
  • 인터페이스 : USB/LAN/RS-232/GPIB/EXT

DC전원공급기 PPX 시리즈

  • 1채널 프로그래머블 고정밀 리니어 DC 전원공급기
  • 출력 채널 : 1CH
  • 출력 전압 : 0~10V/20V/36V/100V
  • 출력 전류 : 0~5A/3A/2A/1A
  • 출력 전력 : 36W/40W/50W/100W/108W
  • 인터페이스 : USB/LAN/RS-232/RS-485/아날로그 제어, GPIB(옵션)

AC/DC 전원공급기 ASR-2000 시리즈

  • AC/DC 전원공급기, ASR-2000/2000R
  • 출력 전압 : AC 0~350Vrms, DC 0~±500V
  • 출력 전력 : 500VA(ASR-2050)/1kVA(ASR-2100)
  • 인터페이스 : USB/LAN/EXT, GPIB/RS-232C(옵션)

다채널 스위칭 DC 전원공급기 PSW-Multi 시리즈

  • Multi-channel: maximum 720W for dual-channel models and maximum 1080W for triple-channel models; output latency between channels with the same voltage module is less than 0.1ms
  • Multiple voltage combinations: low voltage combinations can be selected from 30V/40V/80V/160V; high voltage combinations can be selected from 250V/800V
  • Advanced web server: executes SCPI commands; controls through the server; data log; edit sequence
  • CC/CV priority mode selection is ideal for battery and LED industries
  • Adjustable slew rate
  • High efficiency and high power density power supply
  • Standard communications interfaces: LAN, USB, external analog remote control terminal
  • Optional communications interfaces: GPIB-USB adapter, RS232-USB cable
  • Support LabVIEW Driver
